Aluminum Rubber Sheet Portable Vehicle Barrier with Foldable Design and 13.4kg Lightweight for Low Speed Roads

Aluminum Rubber Sheet Portable Vehicle Barrier with Foldable Design and 13.4kg Lightweight for Low Speed Roads

Anti Collision Vehicle Barricades

Aluminum Rubber Sheet Portable Vehicle Barriers

Foldable Portable Vehicle Barriers

Place of Origin:

CHINA

Brand Name:

RMHs

Model Number:

Parking blocker-JY

Contact Us

Request A Quote
Product Details
Material:
Aluminum Rubber Sheet
Weight:
13.4kg
Color:
Yellow
Structure:
Foldable
Principle:
Friction Increases
Scope Of Application:
Low Speed Road
Payment & Shipping Terms
Minimum Order Quantity
50 PCS
Price
USD 4,053/unit
Packaging Details
Carton packing 3800pcs 40-inch containers
Delivery Time
30
Payment Terms
L/C,T/T
Supply Ability
500 units per month
Product Description
Aluminum Rubber Sheet Portable Vehicle Barriers Foldable
Product Overview

Aluminum Foldable Low speed road Car Portable Vehicle Barricades

The Mobile Vehicle Barrier is suitable for roads with low speeds and is designed to stop intruders. It is an ideal device to control vehicle traffic in urban areas and work zones. When placed in forbidden areas and construction site perimeters, it effectively controls vehicle entry, prevents vehicle collisions and intrusions, and allows vehicles to stop within short distances, reducing injury to people and vehicles.

Aluminum Rubber Sheet Portable Vehicle Barrier with Foldable Design and 13.4kg Lightweight for Low Speed Roads 0
Product Specifications
Specification Details
Material Aluminum Rubber sheet
Dimensions (folded) 0.7*0.53*0.69m
Dimensions (defolded) 1.4*0.53*0.23m
Weight 13.4KG
Color Traffic yellow
Application zone parking interception
Aluminum Rubber Sheet Portable Vehicle Barrier with Foldable Design and 13.4kg Lightweight for Low Speed Roads 1
Product Advantages
  • Aluminum + Rubber Structure: High-strength aluminum profile main body with anti-slip rubber sheet on the bottom - combining lightweight design with efficient braking.
  • Foldable Design: Fits in a car trunk when folded, saving storage space - carry along and use anytime.
  • Lightweight & Portable: Weighs only 13.4 kg - one person can carry and deploy it, reducing on-site workload.
  • Active Anti-Collision: When a vehicle strikes, front wheel lift + lever force transfer + bottom rubber braking bring it to a smooth stop, avoiding violent collision and rollover.
  • Warning & Guidance Integrated: Top can mount an LED arrow board - provides active warning at night or in low light, guiding vehicles to safely bypass.
  • Anti-Slip Stability: Four high-friction rubber pads on the bottom resist displacement when hit, keeping the device stable.
  • Sturdy & Durable: Electrostatic spraying finish - UV-resistant and corrosion-resistant, no fading or rusting during long-term outdoor use.
  • Eco-Friendly: Aluminum is 100% recyclable, meeting green environmental requirements.
Aluminum Rubber Sheet Portable Vehicle Barrier with Foldable Design and 13.4kg Lightweight for Low Speed Roads 2 Aluminum Rubber Sheet Portable Vehicle Barrier with Foldable Design and 13.4kg Lightweight for Low Speed Roads 3 Aluminum Rubber Sheet Portable Vehicle Barrier with Foldable Design and 13.4kg Lightweight for Low Speed Roads 4
Stopping Principle
Step-by-Step Explanation
Step 1: Front Wheel Lift

The vehicle's front wheels roll onto the inclined surface of the device, lifting them off the ground. The drive wheels lose ground traction and cannot continue driving forward.

Step 2: Lever Force Transfer

The impact force generated by the collision is effectively transferred to the ground through the internal lever structure, rather than concentrating on the vehicle or the device itself. This avoids violent collision and structural damage.

Step 3: Bottom Rubber Braking

The four high-friction rubber pads on the bottom of the device create significant friction resistance with the ground, forming strong braking that prevents the device from being pushed forward.

Step 4: Smooth Stop

All three mechanisms work together, forcing the vehicle to stop smoothly and rapidly within a safe distance - no violent collision, rollover, or debris scattering.

Core Features
  • Non-lethal design: Soft stop rather than hard blocking
  • Protects vehicle occupants: Avoids injury from severe impact
  • Protects on-site workers: Prevents vehicles from entering work zones
  • No secondary injuries: No debris scattering upon impact
Application Note

This design is specifically for low-speed environments (e.g., residential roads, municipal work zones), with optimal performance when vehicle speeds are between 20-40 km/h. High-speed scenarios like highways require heavy-duty crash attenuators.

Aluminum Rubber Sheet Portable Vehicle Barrier with Foldable Design and 13.4kg Lightweight for Low Speed Roads 5 Aluminum Rubber Sheet Portable Vehicle Barrier with Foldable Design and 13.4kg Lightweight for Low Speed Roads 6
Packaging Instructions

Packaging Method: One unit per carton, individual carton packaging. The device is folded and placed into an export-grade corrugated carton, with foam or PE foam inside to absorb transport vibration.

Parameter Details
Carton Size 730 × 540 × 120 mm
Net Weight 13.4 kg
Gross Weight Approx. 14.5 kg
Aluminum Rubber Sheet Portable Vehicle Barrier with Foldable Design and 13.4kg Lightweight for Low Speed Roads 7
Frequently Asked Questions
Q1: What is an "Aluminum + Rubber Sheet Portable Vehicle Barrier"?
A: It is a temporary traffic protection device made of high-strength aluminum profile and anti-slip rubber sheet. It is lightweight, foldable, and impact-resistant, used for vehicle isolation in work zones or hazardous areas.
Q2: Why use aluminum and rubber?
A: Aluminum is lightweight, corrosion-resistant, and recyclable. Rubber provides high friction, enhancing braking effect and ground grip. Together, they achieve lightweight design and efficient braking.
Q3: What is an "Anti-Collision Vehicle Barricade"?
A: An anti-collision vehicle barricade is a passive safety device. When a vehicle accidentally strikes it, it absorbs impact energy and guides the vehicle to slow down or stop, protecting workers and vehicle occupants.
Q4: What are the main features of this product?
A: Four core features:
  • Aluminum + rubber structure: Lightweight and efficient braking
  • Foldable design: Easy to carry and store
  • Anti-collision function: Active braking reduces injury
  • Portability: One person can carry and deploy
Q5: How does it work?
A: When a vehicle strikes:
  1. Front wheels are lifted off the ground
  2. Lever structure transfers impact force to the ground
  3. Bottom rubber sheet provides strong friction braking
  4. Vehicle stops smoothly, avoiding violent collision
Q6: What scenarios is it suitable for?
A: Low-speed environments such as residential road construction, municipal temporary isolation, factory internal roads, school zones, parking lots.
Q7: Why is it NOT suitable for highways?
A: Highways involve high speeds and large impact energies. This product is designed specifically for low-speed environments. Highways require heavy-duty crash attenuators.
Q8: Why choose this product made in China?
A: China offers:
  • Strict quality control systems
  • Mature aluminum processing industry chains
  • Professional rubber-aluminum composite technology
  • Patented foldable structure design
Q9: One-sentence summary of its value?
A: An aluminum + rubber, foldable, portable anti-collision vehicle barrier - providing effective safety protection for low-speed work zones.
