External Electrostatic Spraying Vehicle Barrier System Aluminum

External Electrostatic Spraying Vehicle Barrier System Aluminum

External Electrostatic Spraying Vehicle Barrier System

Alu Vehicle Barrier System

Portable Vehicle Barricades Welding

Place of Origin:

CHINA

Brand Name:

RMHs

Certification:

ISO9001

Model Number:

TOMARUKUN

Contact Us

Request A Quote
Product Details
Material:
Aluminum
Size:
W320mm*L1070*H860mm
Surface Process:
Electrostatic Spraying
Weight:
25KG
Color:
Yellow/Orange
Usage:
2units/set
Scope Of Application:
The Product Is Suitable For Construction Sites Where Vehicles Are Traveling At Low Speeds, Such As Municipal Road Maintenance, Municipal Road Maintenance And Other Road Sections.
Production Technology:
Welding, Bending
Payment & Shipping Terms
Minimum Order Quantity
200PCS
Price
USD600~850/PCS
Packaging Details
Carton packing 208pcs 40-inch containers
Delivery Time
30
Payment Terms
T/T
Supply Ability
200PCSper1 month
Product Description

Light Japan External Electrostatic Spraying Portable Vehicle Barricades



The Mobile Vehicle Barrier System(Light) is used to intercept low-speed vehicles. When the vehicle hits the product, the rubber plate at the bottom of the device is rubbed against the ground to force the vehicle to stop. The weight of the product is 25kg, and the bottom is equipped with rubber wheels, which is convenient for mobile deployment, and the foldable design is convenient for transportation and storage.

The product has undergone a crash test in Japan, and the test shows that the safety distance is shortened after the vehicle hits the device. It is very popular in Japan, and our company exports to Japan steadily every month.



Product advantages
1.The Mobile Vehicle Barrier System(Light) is made of environmentally-friendly absorption aluminum material, recyclable, safe and reliable in quality.
2. The external electrostatic spraying process is not easy to rust and is suitable for outdoor weather conditions.
3. The bright and eye-catching traffic yellow can be used with our LED arrow board, which has obvious warning effect.
4. Equipped with movable and convenient wheels, convenient to move and easy to carry out modular deployment.
5. The product is foldable design, easy to transport and store.
6. Light weight, reasonable structure design, single person can complete the work of installation, disassembly and storage.



Layout Example

External Electrostatic Spraying Vehicle Barrier System Aluminum 0



 3 meters each setting separation distance of urban road, and 5 meters each of high-speed road.



The Mobile Vehicle Barrier System(Light) was tested and passed the test in Japanese Vehicle Research Institute. And the actual vehicle collision data are as follows:



When the Mobile Vehicle Barrier System(Light) impacts the device at a speed of 40KM/H without brak, it forced to stop after gliding for 3.6m;
at a speed of 40KM/H without brak, it forced to stop after gliding for 8.7m.



Test video



External Electrostatic Spraying Vehicle Barrier System Aluminum 1



Impact Experiment Data
Test speed Stopping distance
40KM/H 3.6M
60KM/H 9.9M

External Electrostatic Spraying Vehicle Barrier System Aluminum 2



The test permise

Test vehicle:2000cc class passemger car rear-wheel drive.

The road is flat and dry. Assuming that brakes are applied.
