Aluminum Rubber Sheet Mobile Vehicle Barrier Anti Ramming
Car Park Barriers vehicle barricades Mobile Anti-Ramming Barriers Portable Barricades.
This lightweight, portable vehicle roadblock helps control vehicles entering restricted areas and work zones.
It is suitable for low-speed vehicle traffic areas and effectively controls standard passenger vehicles.
Specifications
| Item |
Description |
| Material |
Aluminum alloy + Rubber base plate
• Aluminum acts as an effective energy-absorbing material
• Rubber base plate enhances ground friction for improved stability
|
| Weight |
13.4 kg - Lightweight and easy to carry |
| Folded Dimensions |
0.7 m * 0.53 m * 0.69 m |
| Expanded Dimensions |
1.4 m * 0.53 m * 0.23 m |
| Storage & Portability |
Compact design saves space. Can be stored in a car trunk when not in use |
| Surface Finish |
Electrostatic spraying - provides bright, eye-catching color and rust resistance |
| Suitable Applications |
Work zones, municipal roads, temporary traffic control, etc. |
| Color |
Yellow / Orange |
Structural Composition
- Main Frame: Constructed from high-strength, premium aluminum profiles, formed through bending and welding, achieving an optimal balance between strength and lightweight design
- Anti-slip System: Equipped with four high-friction rubber pads on the base to enhance ground adhesion
- Expansion Interface: Features standardized mounting holes on the top, allowing for the attachment of accessories such as LED arrow indicator boards
- Surface Treatment: Finished with engineering yellow/orange electrostatic coating, offering weather resistance, corrosion protection, and high visibility
Working Principle
When a vehicle collides with the device:
- Wheel Lifting: The sloped design lifts the front wheels off the ground, reducing the vehicle's forward momentum
- Force Transmission and Braking: The impact force is transmitted to the ground through a lever structure, while the rubber pads generate strong friction with the ground, achieving smooth braking
- Energy-absorbing Protection: The aluminum structure disperses impact energy, preventing fragment splashing and reducing the risk of secondary injuries
Product Advantages Comparison
This Product vs. Traditional Solutions
| Comparison Item |
This Product (Simple Parking Device) |
Traditional Traffic Cones / Concrete Barriers |
| Weight |
13.4 kg, lightweight and easy to carry |
Heavy (concrete barriers can weigh over 50 kg), difficult to move |
| Portability |
Foldable, can be stored in a car trunk for transport |
Not foldable, requires special vehicles for transportation |
| Deployment Efficiency |
Can be quickly set up and packed away by one person without tools |
Requires multiple people and is time- and labor-intensive to arrange |
| Function Integration |
Can be equipped with LED indicator boards, combining protection and traffic guidance |
Warning function only; requires additional equipment for traffic guidance |
| Safety |
Energy-absorbing braking design reduces vehicle damage and secondary injuries |
Rigid collision, likely to cause vehicle damage and personal injury |
| Durability |
Aluminum + electrostatic coating, rust and weather-resistant, long service life |
Plastic prone to aging and fading, concrete prone to cracking and weathering |
| Storage Space |
Compact when folded, saves space |
Fixed size, occupies significant storage space |
| Environmental Friendliness |
Recyclable aluminum, sustainable |
Low recyclability for concrete/plastic, prone to generating solid waste |
| Scenario Flexibility |
Modular design allows flexible configuration for complex layouts |
Limited layout options, difficult to adjust |
| Long-term Cost |
One-time investment, reusable for years with low maintenance |
Prone to wear and frequent replacement, higher long-term cost |
Key Advantages Summary
This product significantly outperforms traditional isolation solutions in terms of
lightweight design, portability, safety, functional integration, and lifecycle cost,
making it better suited for the efficient and flexible needs of modern urban temporary traffic control and construction site protection.
Frequently Asked Questions
Q1: What is this product?
A: This is a high-quality mobile vehicle barrier manufactured in China. It adopts a structure of premium aluminum and rubber sheets, designed specifically for temporary traffic control and construction zone protection. It features impact resistance, portability, and flexibility.
Q2: What are the core materials of the product?
A: The main body is made of high-strength aluminum profiles, which are lightweight and durable. The base is equipped with high-friction rubber sheets to enhance ground adhesion and braking effectiveness.
Q3: Why choose this product made in China?
A: China leads the market for such products, with a strict quality control system. This product is manufactured in specialized traffic safety equipment factories, ensuring high quality, strong impact resistance, and compliance with international safety standards.
Q4: Why is the product yellow?
A: It uses engineering warning yellow, which complies with road traffic safety standards. Its high visibility effectively alerts drivers, especially under low-light conditions, enhancing safety.
Q5: Is it effective in preventing collisions?
A: Yes. Through the triple mechanisms of aluminum energy absorption, lever mechanics design, and rubber sheet ground braking, it achieves smooth vehicle stopping within a safe distance, reducing collision damage.
Q6: Is it easy to move and store?
A: Highly portable. It weighs only 13.4kg and features a foldable design. When folded, it occupies minimal space and can easily fit into a vehicle trunk, making it suitable for frequent deployment and relocation.
Q7: What scenarios is it suitable for?
A: It is widely used in municipal road construction, temporary traffic control, event site isolation, parking lot guidance, residential area maintenance, and other scenarios requiring quick setup.
Q8: How do Chinese factories ensure quality?
A: Strict quality control is implemented throughout the process, from material selection and structural testing to surface treatment, ensuring each product meets high strength, corrosion resistance, and long lifespan requirements. Reliable after-sales support is also provided.
Q9: Can it be customized?
A: Yes, customization services are available, such as corporate logo printing, size adjustments, and accessory combinations, to meet diverse scenario needs.
Q10: How to purchase this leading Chinese anti-ramming barrier product?
A: Orders can be placed through official channels or authorized distributors, offering original factory warranties and technical support to respond quickly to global customer needs.
